當前位置:主頁 > 產品目錄 > 芯片開封設備 > 芯片銑磨拋光儀 > Allied 超精密芯片銑拋機 X-PREP?

Allied 超精密芯片銑拋機 X-PREP?

簡要描述:The X-Prep? is a specialized 5-axis CNC-based milling/grinding/polishing machine designed to support electrical and physical failure analysis techniques and other applications requiring high precision sample preparation.

  • 更新時間:2024/10/25 0:00:00
  • 訪  問  量:6700
  • 產品型號:X-PREP
詳細介紹











It features a wizard-based, user-friendly, intuitive interface that guides the operator through a screen sequence.  As each screen appears, instruction is provided to the operator, ensuring every parameter and function is defined before operation.  Help  buttons on each screen provide access to additional explanation and instruction.
A high-definition (720p) color camera projects a magnified, razor-sharp image of the sample onto the touch screen to help the operator define the X/Y milling/grinding/polishing boundary.
Automatic tilt adjustment levels the sample plane parallel to the X/Y plane of the cutting tool.  Unevenly mounted or tilted samples can easily be leveled using this functionality.
A variety of fixtures and accessories are available to accommodate various sample types and sizes.




FEATURES

Easy-to-use, wizard-based workflow guides the operator through system setup to define: X/Y/Z milling position; X/Y milling rate; Z-force; Z-increment; milling pattern/tool path; tool overlap and more   Three (3) modes of control: Position (Milling/Grinding); Position Force (Grinding/Polishing); Floating Force (Polishing)
Optional 3D Software Module adds functionality/capability that includes: automatic 3D mapping/profiling; convex & concave profile deprocessing; and Excel® profile visualization/profile manipulation macro   Requires no G-coding or programming knowledge
Motorized tilt stage provides automatic, closed-loop 3-point leveling of the sample and custom leveling, 0.5 micron resolution   Live video navigation to define X/Y milling region
Closed-loop Z-axis positioning, 0.1 micron resolution, 1 micron accuracy   Closed-loop X/Y-axis positioning, 1 micron resolution
12" color LCD, touch-screen graphic user interface   Closed-loop Z-axis force control, 0.5 to 10 N
Universal tool collet uses 3 mm x 1.5" (38 mm) length tools (0.25 mm - 12 mm grinding/polishing tip)   100 x 100 mm milling region
Weight: 185 lb. (84 kg)   Dimensions: 21" W x 27" D x 25" H (533 x 686 x 622 mm)
Designed & manufactured by Allied in the USA    Two (2) year warranty
